Grouting and circulation device
FAC type grouting and circulation device is a wellhead tool for grouting and circulation when running casing. When the casing is lowered, the device performs real-time grouting; when circulation is required, the device can quickly circulate without installing a circulation head. The operating environment of the wellhead is improved, and the reliability of casing operation is improved.
The drill bit shackle, also known as the drill bit box, is mainly used for the loading and unloading of drill bits during drilling and workover operations. Users should choose the same drill bit shackle according to the different types of drill bits.
The connection plate of the bit loader is mainly connected with the pin to drive the main core filling and the bit shackle, which is a torque transmission device.
The drift diameter gauge is a special tool used to check the diameter of the pipe string. It is mainly used to detect whether the diameter size of the inner hole such as casing, tubing, drill pipe or drill collar meets the standard, and is a common detection tool for downhole operation. The company can according to customer demand production of metal, nylon, Teflon and other materials of various specifications of the diameter gauge.
The company according to API Spec 7K production of the core hook set has two hook (1021) and four hook (6699) two kinds of specifications. Among them, two hooks (1021) have two large hooks for lifting and carrying the lining; four hooks (6699) have four large hooks for lifting and carrying the core patching of the rotary table and the casing.
Quick-release thread protector
The quick-release thread protector is a simple tool used to protect the thread of the pipe string during the transportation and use of the tubing and casing. The thread protector can be easily locked and loosened by operating the locking handle to achieve the purpose of protecting the thread.
The SG-type tucker is suitable for quick tucting of tubing and casing, which is easy to operate and can effectively prevent the damage to the thread of the pipe string during the tucker process. The buckle is clamped on the coupling of the female buckle of the pipe column, and the male buckle of the pipe column is guided into the female buckle of the pipe column through the conical surface of the buckle.
The mud hanging board is used to hang and remove mud during drilling, and is generally installed on pneumatic slip or core filling. When the drill pipe passes through the mud scraper, the mud on the surface shall be clear directly. Can be used in a single piece, can also be used in pairs. Specifications for 2.3/8~6.5/8 drill pipe.
TXGN casing operation device (Casing Running Tool) is a mechanical integrated casing tool. The device is installed on the top drive drill pipe joint, and its operation in the clamping and rotation direction is carried out by the driller, and it is controlled to mechanically activate and lose hands. Installation and disassembly is simple and fast, without external pipelines and power sources.
DC collar lifter is a conversion device used to hold and lift drill collars in oil and gas drilling and workover operations. The product shall be designed and manufactured according to API Spec 8C Specification for Drilling and Production Hoisting Equipment.
Our company produces a complete range of dental plates, which not only cover the wellhead equipment in oil drilling and repairing, such as tongs, power tongs, slips, chucks and other equipment, but also involve the application of equipment in other industries such as disassembly and assembly racks, trenchless drilling rigs and so on. The dental plate is made of high quality alloy steel, and after chemical heat treatment, the surface hardness is high, the core hardness is suitable, it has the advantages of wear resistance, corrosion resistance and long service life.
